Steam Test

Steam test is almost similar to air test. Instead of injecting air, we injected steam into the vessels and pipelines. The reason we conduct steam test is to check for any leakages in the vessels and pipelines. However, unlike air test, steam test is easier to detect leak because steam will visibly shoot out from the leaking point when the pressure is already high (about 1.5 to 2 bars).

It is not necessary to maintain the steam pressure higher than 2 bars as it is already more than sufficient. Applying more steam will only be wasting time, energy and money. In addition to that, it will take longer time to release the steam after completing the process.

For our case, we did steam test at the beginning and at the end of the shutdown. Both were necessary (depending on the condition of the plant). We identified the leaking points and welded them from the earlier test. The final steam test was carried out to double check before plant start-up. Both steam tests have their own downside. The first one will delay cooling of vessels, because steam is hot. Therefore, upon opening the manhole, we have to allow at least 1/2 a day before entering the vessels. Another downside which applied for both earlier and later steam tests were the amount of water produced as condensate from the steam. During plant cleaning, existence of water is not really a problem. However, during plant start-up, water has to be fully drained before pumping oil into plant. Having a mixture of water and oil will create various problem including oil quality.

Labels: ,

posted by Kipas Repair JB @ 9:01 PM, ,

Air Test Before Plant Start-Up

The excruciating plant shutdown was finally over on Saturday. We started-up the plant on Saturday 2200 hrs. Hopefully everything will run silky smooth. We conducted both air and steam tests twice in two different sections in the plant. From the first air test (at the bleaching section), we hold the air pressure inside the vessels and pipelines at 1.5 bar (it took about 1 hour ++ to build the pressure up to 1.5 bar). The pressure dropped to 1.0 bar in 1.5 hours. This indicates that there were some leakages in the system and we need to search for it. Supervisors and plant operators hunted for the leaking points, equipped with alkaline solution to detect leaking air by spraying them on the vessels and pipelines. It's like finding a needle in a haystack, the leak could be anywhere on the pipe surface. After numerous sprays and long search for it, we acquired quite a number of tiny bubbles. Leak can simply be detected when bubble appeared from the leaking points. They were marked and maintenance fitters attended and welded them after we released the air.

Releasing air process does not take a short time. That's why we need to coordinate the shutdown properly and effectively. After detecting the leaking points, air was released from the vessels and pipelines. This took about 2 hours. After air pressure is lesser, maintenance fitters welded the leaking points. Upon completion and satisfied with the workmanship of the maintenance team, we repeated the air test, hold it at 1.2 bar. We targeted the previous leaking points, sprayed them and they were all ok except for one point beneath a retention vessel. We released the steam again, called the fitters and asked them to re-weld the point. Confident that the welding work is good, I instructed my supervisor to release the air. There goes another hour, waiting for the air to escape. At that point, bleaching section is ready for plant start-up.

I'll share about the steam test tomorrow.

Labels: ,

posted by Kipas Repair JB @ 7:57 PM, ,

Advanced Measurements, Control and Distributed I/O Monitoring

Just informing, I'll be attending Advanced Measurements, Control and Distributed I/O Monitoring in the Oil, Gas and Energy Industry Seminar. The seminar is free and will be held in Sofitel Palm Resort, Senai, Malaysia this coming Wednesday organized by National Instrument. Get the details below.

Register Online Now

Learn more about this seminar

28/02/2007 | 02:00 P.M. - 05:00 P.M.
Sofitel Palm Resort
Off Jalan Jumbo
Senai, Johor, MY 81250

Registration will ensure that you are allocated a seat as well as the necessary seminar hand-outs. In the event that there are changes to the seminar, we would also be able to inform you immediately.

Register Now
Register Online Now
asean.events@ni.com
Fax: (603) 2148 0710
Phone: (603) 2148 7710 or 1800-887710 (Tollfree)

Labels: , ,

posted by Kipas Repair JB @ 1:17 AM, ,

Shutdown Day 5

Time is running swiftly. We stopped the plant on Monday, and now Friday is over. In day #5, we had the JKKP (Department of Safety & Health - DOSH) inspector inspecting all our pressure vessels and high pressure boiler. Everything was smooth and working perfectly fine. Immediately after the JKKP inspector left, we boxed-up the vessels and high pressure boiler. We fixed back the Niagara filter leaf. We did some cleaning as well. Tomorrow, we are going to complete balance maintenance job. Later, we will carry on with steam and air test. Finally, we shall start up the plant. Hopefully we'll have a perfect start up.

Labels:

posted by Kipas Repair JB @ 12:27 AM, ,

Butterfly Valve

In a production plant, we need a very good process control equipment and system. We learned the theory in a Chemical Engineering subject called Process Control and Instrumentation. It was hard for me to imagine what process control and instrumentation is all about when I studied the subjects few years back.

When I start working in a plant, then everything becomes clear. One of the most important equipment is valve. There are various types of valve. We have butterfly valve, ball valve, gate valve, globe valve, check valve etc. Each type of valve have their own pros and cons as well as functional area. There are a lot of things to talked about valve. However, in this post, I'm going to cover just a little bit about butterfly valve.

The following photos illustrate a typical butterfly valve. It is a 3" Belgium Ventiel (BV) butterfly valve. This valve have created a very serious contamination and lost earlier because it leaks.

A typical butterfly valve. This is a gear type. The gear is used to open or close the disc. The disc is made of stainless steel.

A closer look to the butterfly valve when it is fully open, allowing liquid to flow passing through it. It is now fully open.

The red arrow shows the seat / liner is damaged and worn out. This is one of the reason leakage can occur from a valve. There are various type of seat / liner to choose for different type liquid and process conditions. The disc is half open.

Another angle of the butterfly valve. Extra photo for you to have better comprehension of this piece of equipment.

Later, in coming post, I shall elaborate more about valve. Don't have much time now. Need to go to work.

Labels: ,

posted by Kipas Repair JB @ 10:53 AM, ,

Wet Wet World

It was day 4 of the plant shutdown and it's nearly coming to an end. It was also a wet wet world in the plant. We have to do a lot of washing and cleaning. Tomorrow will be the JKKP inspection day and we have to ensure that the plant and pressure vessels are perfect and clean. Just now, we removed scrap metal, spent earth, damaged insulation and other waste / rubbish. Darkish and dirty floor with oil traces was mopped and cleaned. In general, I'm pleased with the work performed by my down line.

Labels:

posted by Kipas Repair JB @ 1:03 AM, ,

Electrical Problems and Preventive Measures

To run a plant , electricity is one of the most important utilities besides water and natural gas. Electricity is required to run the motors, pumps, control panel, control system, lightings, cooling tower fans, etc. If electricity is suddenly cut-off due to what ever reasons, the plant will immediately be affected. Pump would not run and all valves must be immediately close to contained the oil. Vacuum system will fail and oil quality will be off-spec, hence the oil must be rejected to the crude storage tank. All factory or plants spend tremendous amount of electricity to run a plant besides using it for basic lighting, air conditioner, PC, server etc.

I am not very good in electrical subject but I have to know and learn few of the basic electrical stuff because it is required to run a plant. I learned about it from the charge man, electrical executives and supervisors. Here I list down some of the major electrical problems that normally would occur. At least it can give us some idea on what potential problem can occur from the electrical perspective.


Major Electrical Problems:
(A) Over-Current
(B)
Earth Leakage

(C)
System failure due to lack of maintenance

(A)
Over-current
Caused of over current:
(1)
Excessive heat generated: additional equipment installed without upgrading panel board and cable.

(2)
Motors / Equipment Failure
Motors that are not maintained properly require more power/current e.g. air conditioning system that is not serviced may demand more current.


Maintenance Wise

1. Maintain the equipment to make sure current demand is at rated capacity.
2. Regular maintenance and cleaning - Visual checking and Infra-red temperature checking (annually)

Over-current protection & Prevention Equipment

(1) MCB (miniature circuit breaker) – for current <>

(2) MCCB (moulded case circuit breaker) – for current > 100 A (e.g. motors)

(3) ACB (Air circuit breaker) - > 400 A (main board)


(B) Earth Leakage

(1) All electrical equipment must be properly earthed

- To protect people from being electrocuted

(2) All leakages must be brought down to <>

(3) 3 types of earthing relay systems:

(i) EF (earth fault) relay (> 200A, high tension & LV system)

(ii) ELR (earth leakage) relay (<>

(iii) Earth leakage circuit breaker (<60a,>


(C) System failure due to lack of maintenance

Precautions :

(1) Tighten loose connections
(2) Regular calibrations of equipment
(3) Regular cleaning of equipment

Labels:

posted by Kipas Repair JB @ 11:56 PM, ,

2007 Chem Show Conference

I received an email from Chemical Engineering magazine newsletter informing about the 2007 Chem Show Conference to be held in Javits Convention Center, New York from October 30 to November 1, 2007. The conference is calling for papers to be presented and published. The topic s to be covered are as shown below:



How to submit a paper:

They invite abstracts (less than 200 words) for proposed, non-promotional, technical presentations on the above conference topics or related fields. Emphasis should be on modern proven technologies, application of best practices, improvement of return on investment.

Send by March 1, 2007 to: Nicholas P. Chopey at nchopey@che.com, or fax to (212) 621-4694.

Presentations to run for about 25 minutes, followed by 5 minutes for questions and discussion.

Get further details from http://www.che.com/

Labels: , ,

posted by Kipas Repair JB @ 12:41 AM, ,

Plant Shut Down - No Water Supply

Shutdown activity is going on which means a lot usage of water for cleaning purposes. In addition to that we have to conduct "Cleaning in Progress" (CIP) for the shell and tube heat exchanger. CIP is carried out to remove the scale and carbon deposited inside the shell and tube in order to improve the heat transfer. Unfortunately, suddenly the water supply was cut off without any notice. Worse than that, nobody realized the unavailability of the water supply for about 3 hours. Upon realizing it, we have to depend on our reserve water supply which is only about 1500 m3. The reserve water is normally saved for the utility boiler because steam is a necessity to run a plant. If steam is not produced with sufficient pressure, production will be affected and if too less, it will stop all plants.

All activity involving water have to be stopped. We have to save the water for the boiler. The plant shutdown cleaning activity was affected and delayed as well. Luckily, the water supplied was back a few hours later and we continued with our shutdown cleaning activities.

Labels: ,

posted by Kipas Repair JB @ 12:28 AM, ,

Pipeline and Gas Technology Magazine

As usual I have been receiving emails regarding a lots of thing related to chemical engineering. The following is the content of an email that I received from Pipeline and Gas Technology stating that they have a digital copy and you can have it.


Digital Delivery NOW Available

To preview the current issue, click here

Now you can read PipeLine and Gas Technology the same day it's released - days or even weeks ahead of your colleagues.

The digital edition is an exact replica of the print magazine

Automatically includes all published supplements & special technical reports.

Plus, these great features and benefits:

And, there are NO restrictions on who can receive the PipeLine and Gas Technology digital edition.

So, sign up today! Be sure you note your digital delivery preference, and we'll activate/start your subscription with the next available issue.


Hart Energy Publishing
1616 S. Voss Road, Ste 1000, Houston, TX 77057
713.260.6442 (Customer Service) 713.840.1449 (Fax) custserv@hartenergy.com


To be removed from future solicitations, please REPLY, type REMOVE in the subject line and SEND.

Labels: ,

posted by Kipas Repair JB @ 11:01 AM, ,

Plant Shutdown Steam Test

I came home from work and it was already midnight. I like it this way because I can escape the heavy traffic jam. It was quite a hectic day at work especially when the shutdown just started. We have to do a lot of activities to stop the plant. I experienced and learned a lot of things and would like to share it with my loyal readers. The only thing is that, I cannot tell all of it in one shot. Due to time limitations, I will share them bit by bit.

We did the steam test to check and detect leakages in the vacuum pipe. This is because the vacuum system in the plant is poor. We build up the pressure to 1.8 bars and inspected the line. It’s easy to view some leakages because it is simply very obvious because steam came out from it. While we already settled with the number of leakages that we found earlier, we discovered a few more very tiny leakages that is impossible to see. They were extremely small and appeared like a crack. Very small droplet of water appeared out of the pipe after the steam test was set up to 1.8 bars. We marked the leaking points with some red colour spray. The maintenance fitters will possibly weld or clamp or replace the leaking point tomorrow.

I hope after all the discovered leaking pipe problems have been solved, the vacuum system will be improved and the plant will be in a better shape than before.

Labels:

posted by Kipas Repair JB @ 1:45 AM, ,

Plant Shutdown Again
